Alloy Steel ASME SA213 T11 & ASTM A213 T11 Suppliers

ASTM A213 T11 Pipe & Tubes

Sachin Steel is a trusted supplier and stockist of high-quality ASTM A213 T11 Alloy Steel Tubes, widely used in boilers, heat exchangers, and superheaters. SA213 T11 is a seamless ferritic low-alloy steel grade designed with carbon, manganese, phosphorus, sulphur, silicon, chromium, and molybdenum. This composition provides excellent resistance to oxidation and corrosion, making these tubes suitable for high-temperature and high-pressure applications.

SA213 T11 tubes exhibit superior tensile strength of 415 MPa and yield strength of 220 MPa, with elongation up to 30%. With a density of 7.85 g/cm³ and maximum hardness of 179 HB, they deliver outstanding durability and toughness in stress-induced environments. These tubes are manufactured through hot or cold rolling processes, with cold-drawn variants offering enhanced strength and a smooth surface finish.

The manufacturing process ensures seamless construction, eliminating weak weld seams and providing higher load-bearing capacity. ASTM A213 T11 Seamless Tubes are widely utilised in power plants, petrochemicals, and thermal plants for steam generation and heat transfer. SA213 T11 Heat Exchanger Tubes efficiently transfer heat between fluids, while SA213 T11 Superheater Tubes enhance boiler efficiency by maintaining consistent steam output.

Heat treatment plays a vital role in achieving optimum properties. The recommended annealing temperature is 1066°C (1950°F), with water quenching or rapid cooling for thinner sections. For hot forging, temperatures range between 1232°C (2250°F) and 982°C (1800°F), ensuring dimensional accuracy and mechanical reliability.

inverted-commas

ASTM A213 T11 Seamless Tube and UNS K11597 T11 Boiler Tube supplier in India

Table Of Content

What is ASTM A213 T11 Tubes?

ASTM A213 T11 tubes are seamless ferritic alloy steel tubes designed for high-temperature service in boilers, heat exchangers, and superheaters. Manufactured with a precise blend of chromium and molybdenum, these tubes offer excellent strength, creep resistance, and durability under elevated temperatures and pressures.

The seamless design enhances their load-bearing capacity and ensures reliable performance in demanding environments. Widely used in power generation and industrial heating systems, ASTM A213 T11 Tubes maintain structural integrity even in corrosive and oxidative conditions, making them a preferred choice for critical operations requiring efficiency, safety, and long service life.

What is ASME SA213 T11?

SA 213 T11 is a seamless ferritic low-alloy steel grade widely used in boilers, heat exchangers, and power generation systems. Manufactured with a balanced composition of carbon, manganese, silicon, chromium, molybdenum, and other elements, these tubes deliver excellent resistance to corrosion and oxidation at elevated temperatures.

With a minimum tensile strength of 415 MPa and yield strength of 220 MPa, SA 213 T11 tubes offer superior durability and toughness in high-pressure environments. They feature a density of 7.85 g/cm³, a maximum hardness of 179 HB, and can be produced through hot-rolling or cold-drawn processes for enhanced performance.

Types of Alloy Steel ASME SA213 T11 & ASTM A213 T11

seamless-pipes

SA 213 T11 Tube Seamless Tube

seamless-tubes

ASTM A213 T11 Heat Exchanger Tube

erw

SA 213 Gr T11 Hot Finished Tube

Rectangular Pipe

SA213 T11 material Cold Drawn Tube

Welded Tube

A213 T11 High Pressure Tube

Square Pipe

ASTM A213 T11 Heater Tube

Request Quote on Types of Alloy Steel ASTM A213 T11 Pipe
inverted-commas

ASTM A213 Gr T11 IBR Tube and T11 Boiler Tube, Check Standard SA 213 Gr T11 Tubing Material Schedules and Sizes Chart as per ANSI / ASME B36.10M

ASTM A213 T11 Specification

Standard ASTM A213 T11, SA213 T11 (with IBR Test Certificate)
Type Seamless / ERW / Welded / Fabricated
Size 6.35 mm OD to 101.6 mm OD
Sch. & Swg. 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk
End Plain End, Beveled End, Treaded
SA213 grade T11 Tube Application Seamless Ferritic Alloy Steel Tube for High-Temperature Service
Origin European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material)
Specifications ASTM A213 & ASTM A209 (T1 , Ta, T1b)
BS/3059/90/PartII/620 & 622
DIN/17175/13CrMo44
DIN/17175/10CrMo910
DIN/17175/15Mo3
SA213 gr T11 Additional Testing NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Craft Cold rolled and Cold drawn
Thickness 3-12mm
available in Form of Round, Square, Rectangular, Hydraulic Etc.
Length Standard
Double &
In Cut length also.
Tolerance Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm
Specialized in ASME SA213 T11 Boiler Tube, SA213 T11 Heater Tube, SA213 T11 Heat Exchanger Tube

SA213 T11 Material Chemical Composition

Element Alloy T11
Mn, % 0.30-0.60
C, % 0.15 maximum
Si, % 0.50-1.00
Cr, % 1.00-1.50
P, % 0.025 maximum
S, % 0.025 maximum
Mo, % 0.44-0.65

SA213 T11 Tube Equivalent

Trade Name  Grade UNS # Heater Tubes
1 1/4 Chrome  T11 K11597  A213 / SA213
2 1/4 Chrome  T22 K21590  A213 / SA213
5 Chrome  T5 K41545  A213 / SA213
9 Chrome  T9 K90941 A213 / SA213
T91 T91 K90901 A213 / SA213
T92 T92 K92460 A213 / SA213

SA213 Chromoly Heater Tube Size Chart

Size 1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3 3 1/2 4 5 6
ID .622 .824 1.049 1.38 1.61 2.157 2.635 3.26 3.76 4.26 5.187 6.407
OD .84 1.05 1.315 1.66 1.9 2.375 2.875 3.5 4 4.5 5.563 6.625
WT .109 .113 .133 .14 .145 .109 .12 .12 .12 .12 .188 .109

ASTM A213 T11 Tube Mechanical Properties

Grade Tensile Strength, MPa Yield Strength, MPa Elongation, % Hardness, HB
T11 415 min 205 min 30 min 179 max

Alloy Steel ASME SA213 T11 Tube Dimensions

Size NPS Pipe O.D. Wall Thickness Pipe I.D. Weight per Foot Standard to XXHY Schedule
Pipe #		 Section Modulus Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 0.85 STD 40 .0407 .0158
    0.147 0.546 1.09 XHY 80 .0478 .0122
    0.188 0.464 1.31   160 .0528 .0088
    0.294 0.252 1.72 XXHY   .0577 .0026
3/4 1.05 0.113 0.824 1.13 STD 40 .0705 .0277
    0.154 0.742 1.48 XHY 80 .0853 .0225
    0.219 0.612 1.95   160 .1006 .0153
    0.308 0.434 2.44 XXHY   .1103 .0077
1 1.315 0.133 1.049 1.68 STD 40 .1328 .0449
    0.179 0.957 2.17 XHY 80 .1606 .0374
    0.250 0.815 2.85   160 .1904 .0271
    0.358 0.599 3.66 XXHY   .2136 .0146
1 1/4 1.66 0.140 1.380 2.27 STD 40 .2346 .0777
    0.191 1.278 3.00 XHY 80 .2913 .0666
    0.250 1.160 3.77   160 .3421 .0549
    0.382 0.896 5.22     .4110 .0328
1 1/2 1.90 0.145 1.610 2.72 STD 40 .3262 .1058
    0.200 1.500 3.63 XHY 80 .4118 .0918
    0.281 1.338 4.86   160 .5079 .0730
    0.400 1.100 6.41     .5977 .0494
2 2.375 0.109 2.157 2.64   10 .4205 .1898
    0.154 2.067 3.66 STD 40 .5606 .1743
    0.218 1.939 5.03 XHY 80 .7309 .1534
    0.250 1.875 5.68     .8045 .1434
    0.281 1.813 6.29     .8666 .1344
    0.344 1.687 7.47   160 .9806 .1161
    0.436 1.503 9.04 XXHY   1.1043 .0922
2 1/2 2.875 0.120 2.635 3.53   10 .6870 .2833
    0.203 2.469 5.80 STD. 40 1.0640 .2487
    0.216 2.443 6.14     1.1169 .2435
    0.250 2.375 7.02     1.2468 .2301
    0.276 2.323 7.67 XHY 80 1.3386 .2202
    0.375 2.125 10.02   160 1.6371 .1842
    0.552 1.771 13.71 XXXHY   1.9971 .1280
3 3.50 0.120 3.260 4.34     1.0411 .4336
    0.156 3.188 5.58     1.3122 .4147
    0.172 3.156 6.12     1.4265 .4064
    0.188 3.124 6.66     1.5342 .3984
    0.216 3.068 7.58 STD. 40 1.7241 .3840
    0.250 3.000 8.69     1.9372 .3672
    0.281 2.938 9.67     2.1207 .3521
    0.300 2.900 10.26 XHY 80 2.2253 .3431
    0.438 2.624 14.34   160 2.8774 .2811
    0.600 2.300 18.6 XXHY   3.4243 .2158
3 1/2 4.0 0.120 3.760 4.98   10 1.3776 .5768
    0.226 3.548 9.12 STD. 140 2.3939 .5136
    0.250 3.500 10.02     2.6001 .4998
    0.281 3.438 11.17     2.8562 .4821
    0.318 3.364 12.52 XHY 80 3.1400 .4617
    0.636 2..728 22.87 XXHY   4.8795 .3085
4 4.5 0.120 4.260 5.62   10 1.7612 .7404
    0.156 4.188 7.24     2.2354 .7156
    0.188 4.124 8.67     2.6296 .6942
    0.203 4.094 9.32     2.8173 .6838
    0.219 4.062 10.02     3.0184 .6725
    0.237 4.026 10.80 STD. 40 3.2145 .6613
    0.250 4.000 11.36     3.3611 .6528
    0.281 3.938 12.67   60 3.7021 .6326
    0.312 3.876 13.97     4.0273 .6126
    0.337 3.826 15.00 XHY 80 4.2713 .5972
    0.438 3.624 19.02   120 5.1790 .5361
    0.531 3.438 22.53   160 5.8997 .4822
    0.674 3.152 27.57 XXHY   6.7927 .4054
5 5.563 0.188 5.187 10.80     4.1161 1.0979
    0.219 5.125 12.51     4.7279 1.0716
    0.258 5.047 14.63 STD. 40 5.4500 1.0391
    0.281 5.001 15.87     5.8644 1.0204
    0.312 4.939 17.51     6.4074 .99647
    0.344 4.875 19.19     6.9358 .9696
    0.375 4.813 20.80 XHY 80 7.4300 .9449
    0.500 4.563 27.06   120 9.2534 .8495
    0.625 4.313 32.99   160 10.7976 .7590
    0.750 4.063 38.59 XXHY   12.0954 .6734
6 6.625 0.109 6.407 7.59   5 3.5769 1.6748
    0.134 6.357 9.30   10 4.3475 1.6488
    0.156 6.313 10.79     5.0107 1.6260
    0.188 6.249 12.94     5.9351 1.5937
    0.203 6.219 13.94     6.3804 1.5780
    0.219 6.187 15.00     6.8261 1.5620
    0.250 6.125 17.04     7.6905 1.5306
    0.280 6.065 18.99 STD. 40 8.4958 1.5008
    0.312 6.001 21.06     9.3416 1.4688
    0.344 5.937 23.10     10.111 1.4391
    0.375 5.875 25.05     10.893 1.4082
    0.432 5.761 28.60 XHY 80 12.224 1.3541
    0.500 5.625 32.74     13.711 1.2909
    0.562 5.501 36.43   120 14.9806 1.2346
    0.625 5.375 40.09     16.1821 1.1787
    0.719 5.187 45.39   160 17.8243 1.0977
    0.864 4.897 53.21 XXHY   20.025 .9784
    1.000 4.625 60.13     21.7719 .8727
    1.125 4.375 66.14     23.1237 .7809

SA 213 Gr T11 Seamless Tube Weight Chart

Size NPS Pipe O.D. Wall Thickness Pipe I.D. Weight per Foot Standard to XXHY Schedule
Pipe #		 Section Modulus Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 0.85 STD 40 .0407 .0158
    0.147 0.546 1.09 XHY 80 .0478 .0122
    0.188 0.464 1.31   160 .0528 .0088
    0.294 0.252 1.72 XXHY   .0577 .0026
3/4 1.05 0.113 0.824 1.13 STD 40 .0705 .0277
    0.154 0.742 1.48 XHY 80 .0853 .0225
    0.219 0.612 1.95   160 .1006 .0153
    0.308 0.434 2.44 XXHY   .1103 .0077
1 1.315 0.133 1.049 1.68 STD 40 .1328 .0449
    0.179 0.957 2.17 XHY 80 .1606 .0374
    0.250 0.815 2.85   160 .1904 .0271
    0.358 0.599 3.66 XXHY   .2136 .0146
1 1/4 1.66 0.140 1.380 2.27 STD 40 .2346 .0777
    0.191 1.278 3.00 XHY 80 .2913 .0666
    0.250 1.160 3.77   160 .3421 .0549
    0.382 0.896 5.22     .4110 .0328
1 1/2 1.90 0.145 1.610 2.72 STD 40 .3262 .1058
    0.200 1.500 3.63 XHY 80 .4118 .0918
    0.281 1.338 4.86   160 .5079 .0730
    0.400 1.100 6.41     .5977 .0494
2 2.375 0.109 2.157 2.64   10 .4205 .1898
    0.154 2.067 3.66 STD 40 .5606 .1743
    0.218 1.939 5.03 XHY 80 .7309 .1534
    0.250 1.875 5.68     .8045 .1434
    0.281 1.813 6.29     .8666 .1344
    0.344 1.687 7.47   160 .9806 .1161
    0.436 1.503 9.04 XXHY   1.1043 .0922
2 1/2 2.875 0.120 2.635 3.53   10 .6870 .2833
    0.203 2.469 5.80 STD. 40 1.0640 .2487
    0.216 2.443 6.14     1.1169 .2435
    0.250 2.375 7.02     1.2468 .2301
    0.276 2.323 7.67 XHY 80 1.3386 .2202
    0.375 2.125 10.02   160 1.6371 .1842
    0.552 1.771 13.71 XXXHY   1.9971 .1280
3 3.50 0.120 3.260 4.34     1.0411 .4336
    0.156 3.188 5.58     1.3122 .4147
    0.172 3.156 6.12     1.4265 .4064
    0.188 3.124 6.66     1.5342 .3984
    0.216 3.068 7.58 STD. 40 1.7241 .3840
    0.250 3.000 8.69     1.9372 .3672
    0.281 2.938 9.67     2.1207 .3521
    0.300 2.900 10.26 XHY 80 2.2253 .3431
    0.438 2.624 14.34   160 2.8774 .2811
    0.600 2.300 18.6 XXHY   3.4243 .2158
3 1/2 4.0 0.120 3.760 4.98   10 1.3776 .5768
    0.226 3.548 9.12 STD. 140 2.3939 .5136
    0.250 3.500 10.02     2.6001 .4998
    0.281 3.438 11.17     2.8562 .4821
    0.318 3.364 12.52 XHY 80 3.1400 .4617
    0.636 2..728 22.87 XXHY   4.8795 .3085
4 4.5 0.120 4.260 5.62   10 1.7612 .7404
    0.156 4.188 7.24     2.2354 .7156
    0.188 4.124 8.67     2.6296 .6942
    0.203 4.094 9.32     2.8173 .6838
    0.219 4.062 10.02     3.0184 .6725
    0.237 4.026 10.80 STD. 40 3.2145 .6613
    0.250 4.000 11.36     3.3611 .6528
    0.281 3.938 12.67   60 3.7021 .6326
    0.312 3.876 13.97     4.0273 .6126
    0.337 3.826 15.00 XHY 80 4.2713 .5972
    0.438 3.624 19.02   120 5.1790 .5361
    0.531 3.438 22.53   160 5.8997 .4822
    0.674 3.152 27.57 XXHY   6.7927 .4054
5 5.563 0.188 5.187 10.80     4.1161 1.0979
    0.219 5.125 12.51     4.7279 1.0716
    0.258 5.047 14.63 STD. 40 5.4500 1.0391
    0.281 5.001 15.87     5.8644 1.0204
    0.312 4.939 17.51     6.4074 .99647
    0.344 4.875 19.19     6.9358 .9696
    0.375 4.813 20.80 XHY 80 7.4300 .9449
    0.500 4.563 27.06   120 9.2534 .8495
    0.625 4.313 32.99   160 10.7976 .7590
    0.750 4.063 38.59 XXHY   12.0954 .6734
6 6.625 0.109 6.407 7.59   5 3.5769 1.6748
    0.134 6.357 9.30   10 4.3475 1.6488
    0.156 6.313 10.79     5.0107 1.6260
    0.188 6.249 12.94     5.9351 1.5937
    0.203 6.219 13.94     6.3804 1.5780
    0.219 6.187 15.00     6.8261 1.5620
    0.250 6.125 17.04     7.6905 1.5306
    0.280 6.065 18.99 STD. 40 8.4958 1.5008
    0.312 6.001 21.06     9.3416 1.4688
    0.344 5.937 23.10     10.111 1.4391
    0.375 5.875 25.05     10.893 1.4082
    0.432 5.761 28.60 XHY 80 12.224 1.3541
    0.500 5.625 32.74     13.711 1.2909
    0.562 5.501 36.43   120 14.9806 1.2346
    0.625 5.375 40.09     16.1821 1.1787
    0.719 5.187 45.39   160 17.8243 1.0977
    0.864 4.897 53.21 XXHY   20.025 .9784
    1.000 4.625 60.13     21.7719 .8727
    1.125 4.375 66.14     23.1237 .7809

Alloy Steel SA 213 T11 Cold Drawn Tube Wall Thickness Tolerance

Hot rolled Outside Diameter, mm Tolerance, %
OD >101.6, W.T. >4.6 +28/-0
OD >101.6, 3.8＜W.T. ≤4.6 +33/-0
OD >101.6, 2.4＜W.T. ≤3.8 +35/-0
OD ≤101.6, W.T. >4.6 +28/-0
OD ≤101.6, 3.8＜W.T. ≤4.6 +33/-0
OD ≤101.6, 2.4＜W.T. ≤3.8 +35/-0
OD ≤101.6, W.T. ≤2.4 +40/-0
Cold Drawn Outside Diameter, mm Tolerance, %
OD >38.1 +22/-0
OD ≤38.1 +20/-0

Alloy Steel ASME SA213 T11 & ASTM A213 T11 Uses

    • Petrochemical Industry
    • Chemical Industry
    • Oil and Gas Industry
    • Pulp & Paper Indusry
    • Power Plant Industry
    • Food Processing Industry
    • Pharmaceuticals Industry
    • Energy Industry
    • Aerospace Industry
Application Industries

FAQs About Alloy Steel ASME SA213 T11 & ASTM A213 T11

 ASME SA213 refers to the specification for seamless ferritic and austenitic alloy steel boiler, superheater, and heat exchanger tubes designed for high-pressure and high-temperature service. Grades like T11, T22, and others fall under this standard.

SA213 T11 tubes are suitable for operating temperatures up to around 600°C (1112°F), making them reliable for high-temperature steam and thermal service applications.

The equivalent materials for SA213 T12 include ASTM A213 T12 and UNS K11562, which are used for similar applications in boiler and heat exchanger systems.

The main difference lies in chromium and molybdenum content. T11 contains 1.25% Cr and 0.5% Mo, while T22 has 2.25% Cr and 1% Mo. This makes T22 stronger with better creep resistance at higher temperatures compared to T11.

Sachin-Steel_Product-CTA

Alloy Steel Pipes & Tubes

Materials

Our Products

Enquire Now

Fill out the form below, and our team will get in touch with you within 24 hours.
