Beryllium Copper Rod Manufacturer and Supplier in India

HOME → Hot Products → Beryllium Copper  → Beryllium Copper Rod

Beryllium Copper Rods

BeCu Rod (Be-Cu) is a precipitation-hardened copper alloy material with high strength, high hardness, high electrical conductivity, wear resistance and corrosion resistance properties. Alloy 25 (UNS C17200) is a typical alloy, which is around 1.8-2.0% Be, and may contain small quantities of Co or Ni. These rods can be used as a result of heat treatment to have high tensile strength and still possess adequate electrical and thermal conductivity. The non-sparking and non-magnetic properties of their material allow them to be used in demanding applications in the oil and gas, mining, electrical equipment, aerospace, precision tooling and hazardous environments. BeCu Rods also have fairly high fatigue, galling and stress-corrosion resistance. Sachin Steel is a reputed manufacturer and supplier of Beryllium Copper Rods in India with different diameters, lengths and finishes.

Request a Quote
Table Of Content

Technical Data

Specifications of Beryllium Copper Rod

Quick Specification Matrix

Details

Primary Grade

UNS C17200 / Alloy 25 / Alloy 172

Standard Specifications

ASTM B196 / ASTM B196M

Welding Standard

RWMA Class 4

Temper Availability

A (Solution Annealed), 1/4H, 1/2H, H, HT, AT (Mill Hardened)

Diameter Range

3 mm to 150 mm (Custom sizes on request)

Available Forms

Round Bar, Hexagonal Bar, Square Bar, Flat Bar

Surface Finish

Centerless Ground, Bright Drawn, Turned / Polished

Certification

EN 10204 3.1 / 3.2, NACE MR0175, Third-Party Inspection Available

Chemical Compositions of Beryllium Copper Rod

Element

Min (%)

Max (%)

Beryllium (Be)

1.80

2.00

Cobalt + Nickel (Co + Ni)

0.20

—

Cobalt + Nickel + Iron (Co + Ni + Fe)

—

0.60

Iron (Fe)

—

0.10

Lead (Pb)

—

0.02

Aluminum (Al)

—

0.20

Silicon (Si)

—

0.20

Copper (Cu)

Balance

Balance

Beryllium Copper Rod Mechanical Properties

Temper Designation

Tensile Strength (MPa)

Yield Strength, 0.2% Offset (MPa)

Elongation in 2 in. (%)

Hardness (Rockwell)

A (Solution Annealed)

415 – 540

140 – 240

35 – 60

HRB 60 – 80

1/4 H (Cold Worked)

520 – 650

380 – 550

20 – 35

HRB 75 – 88

1/2 H (Half Hard)

580 – 750

450 – 680

10 – 25

HRB 88 – 96

H (Hard)

620 – 895

480 – 795

2 – 20

HRB 92 – 100

AT / HT (Mill Hardened / Aged)

1,030 – 1,310

860 – 1,170

2 – 6

HRC 36 – 42

Physical Properties of Beryllium Copper Rod

Property

Value

Metric Units

Density

8.25

g/cm³

Melting Range

866 – 982

°C

Coefficient of Thermal Expansion

17.0 × 10⁻⁶

/°C (20°C to 200°C)

Thermal Conductivity

105

W/m·K at 20°C

Electrical Conductivity

22 – 28

% IACS (Aged condition)

Modulus of Elasticity (Tension)

128

GPa

Applications and Industrial Uses of Beryllium Copper Rod

  • Electrical Connectors and Contacts
  • Precision Springs and Spring Components
  • Oil and Gas Downhole Tools
  • Aerospace Components
  • Marine and Subsea Components
  • Non-Sparking Hand Tools
  • Injection Molding and Die Components
  • Valves, Actuators and Locking Components
Application Industries

Frequently Asked Questions

FAQ – Beryllium Copper Rod
What is Beryllium Copper Rod?

Beryllium Copper Rod is a copper alloy rod known for high strength, hardness, conductivity, and fatigue resistance.

What is UNS C17200 Beryllium Copper Rod?

UNS C17200 is a high-strength copper-beryllium alloy rod, commonly known as Alloy 25, with about 1.80% to 2.00% beryllium.

What is Beryllium Copper Rod used for?

It is used for electrical contacts, connectors, springs, aerospace components, tooling, and oil and gas equipment.

Is Beryllium Copper Rod electrically conductive?

Yes. Beryllium Copper Rod provides useful electrical conductivity along with much higher strength than pure copper.

Can Beryllium Copper Rod be heat treated?

Yes. Beryllium Copper Rod can be solution treated and precipitation hardened to improve its strength and hardness.
