Titanium Pipes & Tubes Manufacturer and Supplier in India

HOME → Titanium Alloy → Titanium Pipes & Tubes

Titanium Pipes & Tubes are tubes designed for use in extreme environments where corrosion resistance, strength and control of wall dimensions are required. ASTM B861 specifies seamless pipe made from Titanium & Titanium-Alloy in various grades (Gr 1, 2, 3, 7, 9, 11, 12) for corrosion resistant and elevated temperature service.The minimum tensile strength of annealed Grade 2 is 345 MPa, the minimum yield strength is 275 MPa and elongation of 20% is required. They are available in seamless and welded products for heat exchanges, chemical processes, marine and aerospace applications. Sachin Steel Centre is a source of titanium pipes and tubes, Titanium Grade 2 Pipes & Tubes and Titanium alloys for different applications.

Table Of Content

Specifications of Titanium Pipes & Tubes
Chemical Compositions of Titanium Pipes & Tubes
Titanium Alloy Pipes & Tubes Equivalent Grades
Mechanical Properties of Titanium Alloy Pipes & Tubes
Weight Chart of Titanium Pipes & Tubes
Titanium Alloy Pipes & Tubes Size Chart
Wall Thickness Chart of Titanium Pipes and Tubes
Applications and Industrial Uses of Titanium Pipes & Tubes
Frequently Asked Questions

Technical Data

Specifications of Titanium Pipes & Tubes

Specification / Feature	Details
Specifications	ASTM B861, B862, B338 / ASME SB861, SB862, SB338
Standard	ASTM, ASME, and API
Form	Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipes/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
Size	1/8" NB to 24" NB
Type	Seamless / ERW / EFW / Welded / Fabricated / LSAW Pipes
End Finish	Plain End, Beveled End, Threaded

Chemical Compositions of Titanium Pipes & Tubes

Grade	Titanium (Ti)	Aluminum (Al)	Vanadium (V)	Iron (Fe) max	Oxygen (O) max	Carbon (C) max	Nitrogen (N) max	Hydrogen (H) max
Grade 2	Balance	—	—	0.30	0.25	0.08	0.03	0.015
Grade 5 (Ti-6Al-4V)	Balance (90 min)	5.5 – 6.75	3.5 – 4.5	0.40	0.20	0.08	0.05	0.015

Mechanical Properties of Titanium Alloy Pipes & Tubes

Grade	Density	Melting Point	Tensile Strength (min)	Yield Strength (0.2% Offset, min)	Elongation (min)
Grade 2	4.51 g/cm³	1665 °C	345 MPa (50 ksi)	275 MPa (40 ksi)	20%
Grade 5 (Ti-6Al-4V)	4.43 g/cm³	1632 °C	950 MPa	880 MPa	14%

Titanium Alloy Pipes & Tubes Equivalent Grades

Grade / Standard	Werkstoff Nr.	UNS Number
Titanium Grade 2	3.7035	R50400
Titanium Grade 5	3.7165	R56400

Weight Chart of Titanium Pipes & Tubes

NPS	Outside Diameter (Inches)	Outside Diameter (mm)	Wall Thickness (Inches)	Wall Thickness (mm)	Schedule	Weight (kg/Mtr)	Weight (Lb/ft)
1/2″	0.840	21	0.109	2.76	40 STD	1.268	0.851
1/2″	0.840	21	0.147	3.73	80 STD	1.621	1.088
3/4″	1.050	27	0.113	2.87	40 STD	1.684	1.131
3/4″	1.050	27	0.154	3.91	80 STD	2.195	1.474
1″	1.315	33	0.133	3.378	40 STD	2.501	1.679
1″	1.315	33	0.179	4.547	80 STD	3.325	2.172
1 1/4″	1.660	42	0.140	3.556	40 STD	3.385	2.273
1 1/4″	1.660	42	0.191	4.851	80 STD	4.464	2.997
1 1/2″	1.900	48	0.145	3.683	40 STD	4.048	2.718
1 1/2″	1.900	48	0.200	5.080	80 STD	5.409	3.361
2″	2.375	60	0.154	3.912	40 STD	5.441	3.653
2″	2.375	60	0.218	5.537	80 STD	7.480	5.022
2 1/2″	2.875	73	0.203	5.516	40 STD	8.629	5.793
2 1/2″	2.875	73	0.276	7.010	80 STD	11.411	7.661
3″	3.500	89	0.216	5.486	40 STD	11.284	7.576
3″	3.500	89	0.300	7.620	80 STD	15.272	10.253
4″	4.500	114	0.237	6.020	—	16.073	10.790
4″	4.500	114	0.337	8.560	—	22.318	14.983
6″	6.625	168	0.188	4.775	—	19.252	12.924
6″	6.625	168	0.203	5.516	—	20.739	13.923
6″	6.625	168	0.219	5.563	—	22.318	14.983
6″	6.625	168	0.250	6.350	—	25.354	17.021
6″	6.625	168	0.280	7.112	40 STD	58.263	18.974
6″	6.625	168	0.312	7.925	—	31.334	21.036
6″	6.625	168	0.375	9.525	—	37.285	25.031
6″	6.625	168	0.432	10.973	80 XHY	42.561	28.573
6″	6.625	168	0.500	12.700	—	48.719	32.708
8″	8.625	219	0.188	4.775	—	25.233	16.940
8″	8.625	219	0.203	5.156	—	27.198	18.259
8″	8.625	219	0.219	5.563	—	29.286	19.661
8″	8.625	219	0.250	6.350	20	33.308	22.361
8″	8.625	219	0.277	7.036	30	36.786	24.696
8″	8.625	219	0.322	8.179	40	42.352	28.554
8″	8.625	219	0.375	9.525	—	49.216	33.041
8″	8.625	219	0.406	10.312	60	53.085	35.638
8″	8.625	219	0.500	12.700	80 XHY	64.627	43.388
10″	10.750	273	0.188	4.775	—	31.588	21.207
10″	10.750	273	0.219	5.563	—	36.689	24.631
10″	10.750	273	0.250	6.350	20	41.759	28.035
10″	10.750	273	0.307	7.798	30	51.002	34.240
10″	10.750	273	0.344	8.738	—	56.946	38.231
10″	10.750	273	0.365	9.271	40 STD	63.301	40.483
10″	10.750	273	0.438	11.125	—	71.852	48.238
10″	10.750	273	0.500	12.700	60 XHY	81.530	54.735
10″	10.750	273	0.594	15.088	80	95.969	64.429
12″	12.750	324	0.188	4.775	—	37.570	25.222
12″	12.750	324	0.219	5.563	—	43.657	29.309
12″	12.750	324	0.250	6.350	—	49.713	33.375
12″	12.750	324	0.281	7.137	—	55.739	37.420
12″	12.750	324	0.312	7.925	—	61.735	41.445
12″	12.750	324	0.375	9.525	—	73.824	49.562
12″	12.750	324	0.406	10.312	—	79.727	53.525
12″	12.750	324	0.500	12.700	—	97.438	65.415
12″	12.750	324	0.562	14.275	—	108.966	73.154
14″	14.000	356	0.188	4.775	—	41.308	27.732
14″	14.000	356	0.219	5.563	—	48.012	32.233
14″	14.000	356	0.250	6.350	20	54.685	36.713
14″	14.000	356	0.281	7.137	—	61.327	41.172
14″	14.000	356	0.312	7.925	—	67.939	45.611
14″	14.000	356	0.375	9.525	STD	81.281	54.568
14″	14.000	356	0.438	11.125	40	94.498	63.441
14″	14.000	356	0.500	12.700	XHY	107.381	72.090
14″	14.000	356	0.625	15.875	—	132.983	89.278
16″	16.000	406	0.188	4.775	—	47.290	21.748
16″	16.000	406	0.219	5.563	—	54.980	36.910
16″	16.000	406	0.250	6.350	10	62.639	42.053
16″	16.000	406	0.281	7.137	—	70.268	47.174
16″	16.000	406	0.312	7.925	20	77.866	52.275
16″	16.000	406	0.344	8.738	—	85.677	57.519
16″	16.000	406	0.375	9.525	30 STD	93.213	62.578
16″	16.000	406	0.438	11.125	—	108.433	72.797
16″	16.000	406	0.500	12.700	40 XHY	123.289	82.770
18″	18.000	457	0.219	5.563	—	61.948	41.588
18″	18.000	457	0.250	6.350	—	70.593	47.393
18″	18.000	457	0.281	7.137	—	79.208	53.176
18″	18.000	457	0.312	7.925	20	87.792	58.939
18″	18.000	457	0.375	9.525	STD	105.144	70.588
18″	18.000	457	0.438	11.125	30	122.369	82.152
18″	18.000	457	0.500	12.700	XHY	139.198	93.450
18″	18.000	457	0.562	14.275	40	155.904	104.666
18″	18.000	457	0.625	15.875	—	172.754	115.978
20″	20.000	508	0.250	6.350	—	78.547	52.733
20″	20.000	508	0.282	7.163	—	88.458	59.386
20″	20.000	508	0.312	7.925	—	97.719	65.604
20″	20.000	508	0.375	9.525	20 STD	117.075	78.598
20″	20.000	508	0.438	11.125	—	136.305	91.508
20″	20.000	508	0.500	12.700	30 XHY	155.106	104.130
20″	20.000	508	0.594	15.088	40	183.378	123.110
20″	20.000	508	0.625	15.875	—	192.640	129.328
20″	20.000	508	0.688	17.475	—	211.368	141.901
24″	24.000	610	0.250	6.350	—	94.456	63.413
24″	24.000	610	0.281	7.137	—	106.029	71.183
24″	24.000	610	0.312	7.925	—	117.573	18.932
24″	24.000	610	0.375	9.525	20 STD	140.938	64.618
24″	24.000	610	0.438	11.125	—	164.176	110.219
24″	24.000	610	0.500	12.700	XHY	186.923	125.490
24″	24.000	610	0.625	15.875	—	232.410	156.028
24″	24.000	610	0.688	17.475	40	255.148	171.293
24″	24.000	610	0.750	19.050	—	277.401	186.233
30″	30.000	762	0.250	6.350	—	118.318	79.433
30″	30.000	762	0.281	7.137	—	132.851	89.189
30″	30.000	762	0.312	7.925	10	147.353	98.925
30″	30.000	762	0.375	9.525	STD	176.731	118.648
30″	30.000	762	0.438	11.125	—	205.983	138.286
30″	30.000	762	0.500	12.700	20 XHY	234.647	157.530
30″	30.000	762	0.625	15.875	30	292.066	196.078
30″	30.000	762	0.688	17.475	—	320.817	215.380
30″	30.000	762	0.750	19.050	—	348.988	234.293
36″	36.000	914	0.250	6.350	—	142.180	95.453
36″	36.000	914	0.281	7.137	—	159.672	107.196
36″	36.000	914	0.312	7.925	10	177.133	118.918
36″	36.000	914	0.375	9.525	STD	215.525	142.678
36″	36.000	914	0.438	11.125	—	247.790	166.353
36″	36.000	914	0.500	12.700	20 XHY	282.372	198.570
36″	36.000	914	0.625	15.875	—	351.723	236.128
36″	36.000	914	0.688	17.475	—	386.487	259.467
36″	36.000	914	0.750	19.050	—	420.576	282.353
42″	42.000	1067	0.312	7.925	—	206.914	138.911
42″	42.000	1067	0.375	9.525	STD	248.319	166.708
42″	42.000	1067	0.500	12.700	XHY	33.097	221.610
42″	42.000	1067	0.750	19.050	—	492.163	330.413
48″	48.000	1219	0.375	9.525	STD	284.112	190.738
48″	48.000	1219	0.438	11.125	—	331.404	222.487
48″	48.000	1219	0.500	12.700	XHY	377.822	253.650
48″	48.000	1219	0.750	19.050	—	563.750	378.473
48″	48.000	1219	0.875	22.225	—	655.969	440.383

Titanium Alloy Pipes & Tubes Size Chart

OD (mm)	Wall Thickness (mm)	NPS (Inches)	Schedule	Weight (kg/m)
13.72	1.65	1/4″	10S	0.50
13.72	2.24	1/4″	40S	0.64
13.72	3.02	1/4″	80S	0.81
17.15	1.65	3/8″	10S	0.64
17.15	2.31	3/8″	40S	0.86
17.15	3.20	3/8″	80S	1.12
21.34	2.11	1/2″	10S	1.02
21.34	2.77	1/2″	40S	1.29
21.34	3.73	1/2″	80S	1.65
26.67	2.11	3/4″	10S	1.30
26.67	2.87	3/4″	40S	1.71
26.67	3.91	3/4″	80S	2.23
33.40	2.77	1″	10S	2.13
33.40	3.38	1″	40S	2.54
33.40	4.55	1″	80S	3.29
33.40	6.35	1″	160	4.30
42.16	2.77	1 1/4″	10S	2.73
42.16	3.56	1 1/4″	40S	3.44
42.16	4.85	1 1/4″	80S	4.53
42.16	6.35	1 1/4″	160	5.69
48.26	2.77	1 1/2″	10S	3.16
48.26	3.68	1 1/2″	40S	4.11
48.26	5.08	1 1/2″	80S	5.49
60.33	2.77	2″	10S	3.99
60.33	3.91	2″	40S	5.52
60.33	5.54	2″	80S	7.60
60.33	8.74	2″	160	11.29
73.03	3.05	2 1/2″	10S	5.35
73.03	5.16	2 1/2″	40S	8.77
73.03	7.01	2 1/2″	80S	11.59
88.90	3.05	3″	10S	6.56
88.90	5.49	3″	40S	11.47
88.90	7.62	3″	80S	15.51
88.90	11.13	3″	160	21.67
101.60	3.05	3 1/2″	10S	7.53
101.60	5.74	3 1/2″	40S	13.78
101.60	8.08	3 1/2″	80S	18.92
114.30	3.05	4″	10S	8.50
114.30	6.02	4″	40S	16.32
114.30	8.56	4″	80S	22.67
114.30	13.49	4″	160	34.05
141.30	6.55	5″	40S	22.10
141.30	9.53	5″	80S	31.44
141.30	15.88	5″	160	49.87
168.28	3.46	6″	10S	14.04
168.28	7.11	6″	40S	28.69
168.28	10.97	6″	80S	43.21
168.28	14.27	6″	120	54.75
168.28	18.26	6″	160	68.59
219.08	8.18	8″	40S	43.20
219.08	12.78	8″	80S	65.63
219.08	18.23	8″	120	91.30
219.08	23.01	8″	160	112.97

Wall Thickness Chart of Titanium Pipes and Tubes

Nominal Size (Inches)	O.D. (Inches)	10S	10	40S & Std	40	80S & E.H.	80	160
1/8″	0.405	0.049	0.049	0.068	0.068	0.095	0.095	—
1/4″	0.540	0.065	0.065	0.088	0.088	0.119	0.119	—
3/8″	0.675	0.065	0.065	0.091	0.091	0.126	0.126	—
1/2″	0.840	0.083	0.083	0.109	0.109	0.147	0.147	0.187
3/4″	1.050	0.083	0.083	0.113	0.113	0.154	0.154	0.218
1″	1.315	0.109	0.109	0.133	0.133	0.179	0.179	0.250
1 1/4″	1.660	0.109	0.109	0.140	0.140	0.191	0.191	0.250
1 1/2″	1.900	0.109	0.109	0.145	0.145	0.200	0.200	0.281
2″	2.375	0.109	0.109	0.154	0.154	0.218	0.218	0.343
2 1/2″	2.875	0.120	0.120	0.203	0.203	0.276	0.276	0.375
3″	3.500	0.120	0.120	0.216	0.216	0.300	0.300	0.437
3 1/2″	4.000	0.120	0.120	0.226	0.226	0.318	0.318	—
4″	4.500	0.120	0.120	0.237	0.237	0.337	0.337	0.531
4 1/2″	5.000	—	—	0.247	—	0.355	—	—
5″	5.563	0.134	0.134	0.258	0.258	0.375	0.375	0.625
6″	6.625	0.134	0.134	0.280	0.280	0.432	0.432	0.718
7″	7.625	—	—	0.301	—	0.500	—	—
8″	8.625	0.148	0.148	0.322	0.322	0.500	0.500	0.906
9″	9.625	—	—	0.342	—	0.500	—	—
10″	10.750	0.165	0.165	0.365	0.365	0.500	0.593	1.125
11″	11.750	—	—	0.375	—	0.500	—	—
12″	12.750	0.180	0.180	0.375	0.406	0.500	0.687	1.312
14″	14.000	0.188	0.250	0.375	0.437	0.500	0.750	1.406
16″	16.000	0.188	0.250	0.375	0.500	0.500	0.843	1.593
18″	18.000	0.188	0.250	0.375	0.562	0.500	0.937	1.781

Types of Titanium Wire

Frequently Asked Questions

What are Titanium Pipes & Tubes?

Titanium Pipes & Tubes are tubular products made from commercially pure titanium or titanium alloys. They are valued for their corrosion resistance, strength, low weight and suitability for demanding industrial environments.

Is titanium good for pipes?

Yes. Titanium is well suited for pipes because it offers excellent corrosion resistance, good strength-to-weight performance and strong resistance to seawater and many chemical environments.

What are the downsides of using titanium?

The main disadvantages are higher material cost, more demanding fabrication and welding requirements, and lower wear resistance compared with some harder engineering materials.

What is the difference between Titanium Pipe and Titanium Tube?

Titanium pipe is generally specified by nominal pipe size and schedule or wall thickness, while tube is commonly specified by its outside diameter and wall thickness. Tubes are often used for heat exchangers and instrumentation.

How much does titanium pipe cost?

The price depends on the grade, size, wall thickness, manufacturing method, specification, quantity and surface finish. Custom dimensions and special testing can also affect the final price.

What are titanium tubes used for?

Titanium tubes are used in heat exchangers, condensers, desalination equipment, chemical processing systems, marine equipment, aerospace systems and pharmaceutical equipment.

Titanium Pipes & Tubes Manufacturer and Supplier in India

Technical Data

Specifications of Titanium Pipes & Tubes

Chemical Compositions of Titanium Pipes & Tubes

Mechanical Properties of Titanium Alloy Pipes & Tubes

Titanium Alloy Pipes & Tubes Equivalent Grades

Weight Chart of Titanium Pipes & Tubes

Titanium Alloy Pipes & Tubes Size Chart

Wall Thickness Chart of Titanium Pipes and Tubes

Types of Titanium Wire

Applications and Industrial Uses of Titanium Pipes & Tubes

Frequently Asked Questions

Titanium

Materials

Our Products

Enquire Now

Request a Quote

Quick Links

Products Category

Material We Supply

56/72, ASMA Building, 1st Floor, Kumbarwada Lane, Mumbai 400004
