Tantalum Wire Manufacturer & Supplier

HOME → Hot Products → Tantalum Products → Tantalum Wire Supplier & Manufacturer

Tantalum Wires

Sachin Steel Centre is a most trustworthy manufacturer and supplier of high-quality tantalum wire that provides resistance to heat, corrosion, and long-term durability of the component. We supply Tantalum UNS R05200 wires in different standards and sizes that are used by different industries according to their requirements. With the consistent quality check, stock, and competitive tantalum wire price, make use of the best supplier of this material across the world. This material is used in different industries like chemical processing units, electronics, and aerospace sectors. Whether you need to make precise fine wire for components or durable tantalum wire mesh for a high-performance environment, Sachin Steel Centre makes sure that our customers get the best and premium-grade tantalum wire.

Request Quote
inverted-commas

Tantalum Wires, Tantalum Wire Supplier, Tantalum Wire Exporter, Tantalum Wire Manufacturer, Tantalum Wire Supplier, Tantalum Tungsten Alloy Wire Manufacturer & Exporter in Mumbai, India.

Table Of Content

About Tantalum Wires

Tantalum Wire is made with the pure 99% tantalum-niobium alloy, which provides many benefits, including excellent corrosion resistance, high-temperature and high-electricity endurance. They are mostly used in many industries such as electronics, aerospace, and medical applications. With all of this ability, this material becomes very suitable for customising components.  It also has good chemical prorpeties that make it remain stable in too hot or cold conditions without reacting with concentrated acid, hydrochloric acid, and oxygen in the air. In addition to this, tantalum wire also comes with a high melting and boiling point, with a density of 16.6 g/cm³, which makes it’s good choice for high-temperature applications. Due to its excellent corrosion and chemical resistance, this material can survive below 150 °C and can only be dissolved with hydrofluoric acid. Tantalum metal has the fourth-highest melting point, approximately 2996 °C. Also, the pure tantalum recrystallises at approximately 2200°F (1204 °C).

Tantalum wires are thin and elongated strands of tantalum metal. They commonly come in different diameters and lengths that are used according to need. Tantalum wires also have excellent electric conductivity and corrosion resistance towards high-temperature and corrosion resistance.

Available Types in Tantalum Wires

The tantalum wire comes in different types and forms, and the information about this is given below.

tantalum welding wire

Tantalum Welding Wire

Tantalum Tungsten Alloy Bright Wire

Tantalum Tungsten Alloy Bright Wire

Ta Wire Spool

Ta Wire Spool

Ta Alloy Wire Coil

Ta Alloy Wire Coil

Tantalum Mig Wire

Tantalum Woven Wire Mesh

Tantalum Woven Wire Mesh

Request Quote on Tantalum
inverted-commas

Tantalum RO5252 Wire, R05255 Tantalum Wire Bobbin Stockist, Tantalum UNS R05400 Wire, ASTM B365 Tantalum Wire, Tantalum R05252 Wire, Tantalum Alloy R05252 Spool Wire, Tantalum Welding Wires, Tantalum Filler Wires.

Tantalum Wire Specifications

A tantalum wire specification is important that help you know more about the wire and make a plan according to that. Below are the detailed specifications of tantalum wire.

Standard ASTM B365 ASME SB365
Dimensions ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
Length Cut Lengths: 0.125″ to 72″
No Limit on Spooled Lengths
Diameter 0.0004″ to 0.040″
10 microns to 1.0 mm
Other Sizes on Request
Wire Density 8.89 g/cm3
Ultimate Strength (≥ MPa) 580-750
Wire Resistance (μΩ.m) as standard
Wire Elongation (≥ %) 28-30
Surface Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated
Tempers Tempers range from dead soft annealed to ultra spring temper
Welded Wire mesh Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch
Roll Length: 100feet or 150feet
Wire Mesh Weaving Methods plain weave, twill weave, dutch weave
Technique Cold Rolled, hot rolled
Condition M, Y, 1/2Hard
Offered in a wide range of packages including: Spool
Reel
Coil
Bobbin
Carrier
Custom packaging provided from as low as 1lb to 200lb tapered plastics
Form Filler Wire, Flat Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire, stranded and twisted wire
Test Certificates Tensile Testing
Hardness Testing
Metallographic Inspection / Investigation
Corrosion Testing
Chemical Analysis
Wrap Testing
Elevated Temperature Testing
Stress Rupture Testing (Creep)

Tantalum Wire Chemical Composition

Below is given the detailed chemical composition of the Tantalum wire that tells you about which metals are mixed with this material.

Element R05200 R05400 R05255 R05252 R05240
C 0.01 0.01 0.01 0.01 0.01
O 0.015 0.03 0.015 0.015 0.02
N 0.01 0.01 0.01 0.01 0.01
H 0.0015 0.0015 0.0015 0.0015 0.0015
Fe 0.01 0.01 0.01 0.01 0.01
Mo 0.02 0.02 0.02 0.02 0.02
Nb 0.1 0.1 0.1 0.5 35.0–42.0
Ni 0.01 0.01 0.01 0.01 0.01
Si 0.005 0.005 0.005 0.005 0.005
Ti 0.01 0.01 0.01 0.01 0.01
W 0.05 0.05 9.0–11.0 2.0–3.5 0.05

ASME SB365 Tantalum Wires Equivalent Grades

Just like different types this wire also comes in different grades. That information is provided in the data table below.

STANDARD WERKSTOFF NR. UNS
Tantalum – R05200 / R05400 / R05255 / R05252 / R05240

Tantalum Wire Mechanical Properties

The mechanical properties define the strength and durability of the material. So it’s important to know about that, and for this, we provide a table below on Tantalum mechanical properties.

Grade Diameter，inch (mm)　 tensile strength，psi (MPa)，≥　 　Elongation， ％， ≥
RO5200/RO5400 　0.010(0.254)~0.0149(0.379) 35000 (241) 10
　0.015(0.381)~0.0249(0.633) 35000 (241) 　15
　0.025(0.635)~0.124(3.14) 30000 (207) 　20
RO5252 　0.010(0.254)~0.0149(0.379) 40000 (276) 　5
　0.015(0.381)~0.0249(0.633) 40000 (276) 　10
　0.025(0.635)~0.124(3.14) 40000 (276) 　15
RO5255 　0.010(0.254)~0.0149(0.379) 70000 (482) 　5
　0.015(0.381)~0.0249(0.633) 70000 (482) 　10
　0.025(0.635)~0.124(3.14) 70000 (482) 　15
RO5240 　0.010(0.254)~0.0149(0.379) 35000 (244) 　10
　0.015(0.381)~0.0249(0.633) 35000 (244) 　15
　0.025(0.635)~0.124(3.14) 35000 (244) 　20

Tantalum Wire Physical Properties

The physical properties tell about the melting and other points about the material that is given below.

Density
LBM/in3		 Coefficient of
Thermal Expansion (min/in)-°F		 Thermal Conductivity BTU/hr-ft-°F Specific Heat BTU/LBM -°F Modulus of Elasticity (annealed)2-psi
at 68 °F at 68 – 212°F at 68 – 1832°F at 200°F at 32 – 212°F in tension (E)
0.286 9.2 20.5 9.3 0.12 28 x 106

Tantalum Wire Tolerance Chart

The tolerance level of any material gives information about how much tolerance it can handle, and the information on Tantalum wire tolerance is given below

Diameter MM Dia Tolerance, mm Length, mm Length Tolerance, mm
Forging Drawing Machining
3.0-4.5 – 0.05 – 500-1500 ±2
4.5-6.5 ±0.15 – – 500-1500 ±2
6.5-10 ±0.15 – – 400-1500 ±2
10-16 ±0.15 – – 30-1200 ±2
16-18 ±0.15 – – 200-1500 ±2
18-25 – – ±0.5 – ±2
25-40 – – ±0.5 – ±2
40-50 – – ±0.6 – ±2
50-65 – – ±0.7 – ±2

Tantalum Wire Size Chart

The size chart helps you to order exact measurements of tantalum wires according to your needs, and information about this is given below.

Diameter (mm) Diameter (inch) Supply Form Tolerance (mm) Typical Coil/Spool Weight
0.10 mm 0.004 in Fine wire / Spool ±0.01 1 – 2 kg
0.25 mm 0.010 in Spool / Coil ±0.01 2 – 5 kg
0.50 mm 0.020 in Coil / Spool ±0.01 5 – 10 kg
0.80 mm 0.032 in Coil / Spool ±0.02 10 – 15 kg
1.00 mm 0.039 in Coil / Straight ±0.02 10 – 20 kg
1.50 mm 0.059 in Coil / Straight ±0.02 15 – 25 kg
2.00 mm 0.079 in Coil / Straight ±0.02 20 – 30 kg
3.00 mm 0.118 in Coil / Straight ±0.03 25 – 40 kg
4.00 mm 0.157 in Straight Length ±0.03 30 – 50 kg
5.00 mm 0.197 in Straight Length ±0.05 40 – 60 kg
tantalum welding wire

Tantalum Wires Price Details

The prices of the Tantalum Wire products vary from country to country. So to get the best price list and ready-to-ship stock information, click on the request quote button. Sachin Steel Center always maintains a ready-to-ship stock of all standards of items and can easily ship at the best price: ASME SB365 Tantalum Tungsten Alloy Wires, Coil Wire, Ribbon Wires, Wiremesh, Wire Bobbin, etc.

Request Quote on Tantalum Wires

Tantalum Wires Uses

Tantalum wires are commonly used in different industries because they come with excellent corrosion resistance and strong mechanical performance. Many chemical processing industries use this material to make heat exchangers, pumps, and vessels that are made to handle highly corrosive fluids. In electronics, these wires are used to make different capacitors and precise components. The biocompatibility features of this material make it an ideal choice for medical devices and implants. Tantrum wires are also used in aerospace and nuclear applications where high pressure and temperature are required. Below is the list of other industries that use Tantalum Wires.

  • Oil & Gas Industry
  • Power Plant Generation
  • Marine Industry
  • Petrochemical Industry
  • Chemical Industry
  • Aerospace Industry
  • Sugar Industry
Application Industries

Other Types Of Tantalum Wire

Tantalum wire also comes in a different other types, that list are listed below.

  • Tantalum Alloy Square Wire
  • Ta Alloy Wire Rope
  • Tantalum Welding Wire
  • Tantalum Tungsten Alloy Spring Hard Quality Wire
  • Tantalum Industrial Wires
  • Tantalum Alloy Tig Wire
  • Tantalum Wire Rope
  • Tantalum Cold Heading Wire
  • ASME SB365 Tantalum Wire
  • Tantalum Cold Drawn Wire
  • Tantalum Tungsten Alloy Spool Wire
  • Tantalum Wire Mesh Manufacturer
  • UNS R05200 Wire
  • Tantalum Alloy Filler Wire
  • Tantalum Alloy Spring Wire
  • Tantalum Ultra Fine Wires
  • Tantalum Alloy Netting Wiremesh
  • Tantalum Knitting Wire
  • Ta Alloy Wire Bobbin
  • Tantalum Wire
  • ASTM B365 Tantalum Wire
  • Tantalum Knitted Wire Mesh
  • Tantalum Mig Wire
  • Tantalum Wire Price
  • Tantalum Alloy Welding Wire
  • ASTM B365 Tantalum Woven Wire mesh
  • Wire Mesh Tantalum
  • Tantalum Coil Wire
  • Tantalum Weld Mesh
  • Tantalum Alloy Crimped Wire Mesh
  • Ta Wire Mesh
  • Tantalum Tungsten Alloy Wire cloth

Frequently Asked Questions About Tantalum Wire

Tantalum wire is mostly used in chemical processing units, electronics, medical devices, and for high-temperature components.

Yes, the tantalum metal is more expensive than most other metals due to its extraction method and rarity in nature.

Yes, Tantalum metal is heavier than any other metal because of its high density.

Yes, it’s a good conductor of electricity, which is why many electronics industries use this wire to make precise components for their devices.

Yes, in many countries, there is international regulation to check the purity, sourcing, and export compliance.
