Titanium (Ti) Grade 2 Pipe/Tube Fittings & Forged Fittings

HOME → Our Products → Fittings → Titanium Pipe/Tube Fittings & Forged Fittings  → Ti GR2 Pipe/Tube Fittings

Manufacturer & Supplier of Ti GR2 Pipe/Tube Fittings

Ti GR2 Pipe/Tube Fittings
Sachin Steel Centre is a leading manufacturer, supplier, and exporter of high-quality Titanium Grade 2 Pipe, Tube & Forged Fittings. Utilizing advanced manufacturing technologies, we produce Titanium Gr. 2 fittings with precision, ensuring excellent corrosion resistance, strength & durability for various industrial applications. We offer a wide range of custom and standard sizes, shapes, and thicknesses to meet the specific needs of our clients in industries. With stringent quality assurance processes and a commitment to on-time delivery, we provide reliable and durable solutions, ensuring each product meets national and international standards. At Sachin Steel Centre, we handle bulk orders with precision, ensuring the highest standards of quality and service in every shipment.
inverted-commas

ASTM B363 Titanium Alloy Gr 2 Pipe Fittings, Ti Gr.2 Stub End, Titanium Gr 2 Buttweld Elbow, Grade 2 Titanium Reducing Tee, Titanium Gr 2 Pipe Fittings in India, ASTM b363 wpt2 elbow Manufacturer, Titanium Grade 2 Forged Fittings.

Table Of Content

Know More About Titanium Grade 2 Pipe Fittings

“Ti GR 2 fittings” refers to pipe & tube fittings, they are known for their lightweight yet robust nature. These fittings are widely used in industries such as marine, aerospace, chemical processing, and petrochemical, where durability and resistance to harsh conditions, including chlorides and high temperatures, are essential. Ti GR 2 pipes and tubes are commonly used in heat exchangers and condenser tubing, offering superior thermal conductivity and the ability to withstand temperatures up to 3040°C. The forged fittings including elbows, reducers, tees & flanges are designed for high performance, providing secure, leak-proof connections and reliable fluid flow. Available in various sizes, pressure ratings & configurations, these fittings are easy to weld and fabricate, making them suitable for complex piping systems. With their biocompatibility, excellent mechanical properties, and resistance to corrosion, Ti GR 2 fittings are the preferred choice for critical applications requiring long-lasting, high-performance solutions.

Titanium Gr 2 Pipe Fittings Types

Titanium Gr 2 Elbow

Tee

Titanium Gr 2 Tee

Stub End

Titanium Gr 2 Stub End

Titanium Gr 2 Reducer

End Cap

Grade 2 Titanium End Cap

Forged Cross

Titanium Grade 2 Forged Cross

Request Quote on Types of Titanium Gr 2 Pipe Fittings
inverted-commas

Titanium Gr-2 Buttweld Pipe Caps, ANSI B16.9 Ti Alloy Gr 2 Pipe Fittings, Titanium Gr 2 Equal Tee, Titanium Grade 2 Welded Pipe Fittings, Titanium Alloy Grade 2 End Pipe Cap, Ti Alloy Gr-2 Pipe Elbow, Titanium Alloy Gr 2 Pipe Fittings Supplier.

Specification of Titanium Grade 2 Pipe Fittings

Dimensions ASME B16.28, MSS-SP-43, ASME/ANSI B16.9, BS4504, BS10, BS4504, BS1560,
Thickness SCH10, SCH 80, SCH 100, SCH20, SCH30, STD SCH40, SCH 160, XXS, SCH60, XS, SCH 120, SCH 140, available with NACE MR 01-75
Type DN15-DN1200
Connection Welding
Bending Radius R=2D, 3D, 5D, 6D, 8D, 1D, 10D or Custom
Manufacturing process Press, Forge, Push, Cast, etc.
Specialized manufacturer of Tees, Crosses, Reducers, 90º Elbows, Stub End, Pipe Bend, 45º Elbows, Pipe Cap

Titanium Gr 2 Tube Fittings Equivalent Grades

STANDARDWNR.UNS
Titanium Gr.23.7035R50400

Chemical Composition of Titanium Alloy Gr2 Forged Fittings

GradeTiCFeHNOAlV
Ti Grade299.2 min0.1 max0.3 max0.015 max0.03 max0.25 max––

Titanium Gr 2 Butt weld Pipe Fittings Mechanical Properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Titanium Gr. 2 4.5 g/cm3 1665 °C (3030 °F) Psi – 49900 , MPa – 344 Psi – 39900 , MPa – 275 20 %

Size Range of Gr 2 Titanium Buttweld Pipe Fittings

Product Description Size Range
Titanium Alloy Grade 2 Seamless ButtWeld Fittings 1/2″ – 10″
Titanium UNS R50400 Welded Pipe Fittings 1/2″ – 48″
Grade 2 Pure Titanium Fittings 1/2″ NB – 24″ NB

Titanium 3.7035 Forged Fittings Weight List

Name WorkingPress. 1/4” 3/8” 1/2” 3/4” 1” 1-1/4” 1-1/2” 2” # per 100 pcs
90º Ells S/W 3000# 22 29 53 86 139 198 286 400 –
90º Ells Screw 3000# 29 53 86 139 198 286 400 1452 –
45º Ells S/W 3000# 22 38 53 86 139 198 374 396 –
45º Ells Screw 3000# 29 53 86 139 198 374 600 800 –
Tees S/W 3000# 31 40 73 106 158 220 317 572 –
Tees Screw 3000# 40 73 106 158 220 317 512 2090 –
Union Screw – – – – – – – – – –
Union S/W – – – – – – – – – –
Coupling S/W 3000# 9 18 26 40 92 152 229 462 –
Coupling Screw 3000# 9 18 26 40 92 152 229 462 –
Caps S/W 3000# 11 13 24 37 62 114 147 297 –
Caps Screw 3000# 11 13 24 37 62 114 147 297 –
Hex. Head Plugs 3000# 4 7 18 26 48 86 99 198 –
Sq. Head Plugs 3000# 2 4 9 18 33 57 73 136 –
Hex. Bushing 3000# 7 7 9 13 18 42 44 136 –
Flush Bushing 3000# 4 4 7 9 15 33 37 132 –

Grade 2 Titanium Fittings Dimensions Chart

NPS T OD F G R
Type B		 R
Type A
3/4 2.11 26.7 50.8 42.9 0.76 3.05
1/2 2.11 21.3 50.8 34.9 0.76 3.05
1.1/4 2.77 42.2 50.8 63.5 0.76 4.83
1 2.77 33.4 50.8 50.8 0.76 3.05
1.1/2 2.77 48.3 50.8 73 0.76 6.35
2.1/2 3.05 73 63.5 104.8 0.76 7.87
2 2.77 60.3 63.5 92.1 0.76 7.87
3.1/2 3.05 101.6 76.2 139.7 0.76 9.65
3 3.05 88.9 63.5 127 0.76 9.65
4 3.05 114.3 76.2 157.2 0.76 11.18
6 3.40 168.3 88.9 215.9 1.52 12.7
5 3.40 141.3 76.2 185.7 1.52 11.18
8 3.76 219.1 101.6 269.9 1.52 12.7
24 6.35 609.6 152.4 692.2 1.52 12.7
12 4.57 323.9 152.4 381 1.52 12.7
10 4.19 273.1 127 323.9 1.52 12.7
14 4.78 355.6 152.4 412.8 1.52 12.70
18 4.78 457.2 152.4 533.4 1.52 12.70
16 4.78 406.4 152.4 469.9 1.52 12.7
20 5.54 508 152.4 584.2 1.52 12.70

Physical Properties of Titanium Gr 2 Forged Fittings

Physical Properties Metric English
Density 4.51 g/cc 0.163 lb/in³

Titanium Grade 2 Pipe Fittings Application

  • Petrochemical Industry
  • Oil and Gas Industry
  • Chemical Industry
  • Power Plant Industry
  • Energy Industry
  • Pharmaceuticals Industry
  • Pulp & Paper Industry
  • Food Processing Industry
  • Aerospace Industry
  • Refining Industry
Application Industries

Specialized in Following Titanium Grade 2 Fittings

Ti Gr 2 Socket Weld Pipe Fittings Manufacturer In India Titanium Gr.2 Socket weld Forged Fittings
Titanium Gr.2 Socket weld Fittings Titanium 3.7035 Forged Fittings
Titanium Gr 2 Forged Socket weld Fittings ANSI/ASME B16.11 Titanium Gr 2 Threaded Plugs
Titanium Grade 2 Forged Fittings Price List Titanium Gr 2 Forged Fittings Manufacturer
Titanium Alloy Gr 2 Round Head Plugs Grade 2 Titanium Forged Threaded Fitting
UNS R50400 Forged Fittings Grade 2 Titanium Hex Head Plug Manufacturer in Mumbai
ASTM B381 Grade 2 Titanium Forged Fittings Titanium Gr 2 Forged Fittings Supplier
Ti Alloy Gr 2 90° Forged Elbow ASTM B381 Grade 2 Titanium Fittings
Grade 2 Titanium Alloy Welding Boss Titanium Alloy Gr.2 Forged Fittings
Titanium Grade 2 SW Fittings Ti Alloy Grade 2 Screwed Fittings Stockist
Titanium Gr 2 Forged Fittings Supplier In Mumbai Titanium Gr.2 Forged Fittings Exporters
Ti Alloy Grade 2 High Pressure Forged Fittings Titanium Gr 2 Barrel Nipple
Titanium Grade 2 Threaded Fittings Grade 2 Titanium 45 Degree Elbow
Titanium Gr.2 Forged High Pressure Pipe Fittings ASME/ANSI B16.11 Grade 2 Titanium Forged Fittings
Titanium Grade 2 Industrial Forged Fittings Titanium Grade 2 Forged Pipe Fittings Dealers in India
Titanium Alloy Gr 2 Socket Weld Fittings Exporter In India Titanium Gr2 Forged Fittings at Best Price List In India
ASME SB381 Grade 2 Titanium Forged Fittings Titanium Grade 2 Square Head Plugs Wholesaler

Frequently Asked Questions About Ti GR2 Pipe/Tube Fittings

Titanium Butt Weld Fittings are piping components used to connect pipes of different sizes and shapes in a piping system. Made from corrosion-resistant titanium, they provide high strength, durability, and can withstand elevated temperatures and pressures, making them suitable for demanding applications.

Titanium Gr. 2 Tee Fittings ensure efficient fluid distribution, leak-proof connections, excellent corrosion resistance, non-magnetic properties, and minimal pressure drop in piping systems.

Yes, Titanium Gr. 2 naturally forms a protective oxide layer on its surface, which prevents corrosion and ensures long-term durability, even in seawater and marine applications.
