Stainless Steel 316Ti Pipe & Tube

HOME → Our Products → Pipe & Tube → Stainless Steel Pipes & Tubes → Stainless Steel 316Ti Pipe & Tube

Stainless Steel 316Ti Pipe Supplier

Sachin Steel Center is a trusted manufacturer and supplier of Stainless Steel 316Ti Pipe & Tube, offering high-quality products that meet international standards. Our range includes SS 316Ti seamless pipes, 316Ti welded tubes, AISI 316Ti square tubing, and ASTM A312 TP316Ti stainless steel pipes. Designed with Titanium-stabilized austeniTic stainless steel, these pipes and tubes provide superior resistance to corrosion, pitTing, and high-temperature oxidation.

We supply stainless steel 316Ti pipes in various sizes, thicknesses, and finishes such as polished, bright annealed, and hairline. Our SS 316Ti tubes are widely used in chemical processing, heat exchangers, marine equipment, oil & gas pipelines, pulp and paper, and other demanding industries. With excellent mechanical strength, toughness, and durability, 316Ti stainless steel tubes perform well even in complex and corrosive environments.

As one of the leading SS 316Ti pipe suppliers in India, Sachin Steel Center provides cost-efficient solutions with reliable quality. We offer customized dimensions as per ASTM A249, ASTM A269, and ASTM A312 TP316Ti specifications, ensuring every 316Ti pipe and tube meets strict quality standards. Our products are available in seamless, welded, ERW, and EFW forms to cater to diverse application needs. Choose Sachin Steel Center for premium 316Ti stainless steel pipes and tubes combining precision manufacturing, consistent performance, and competitive pricing.

Stainless Steel 316Ti Tube manufacturer, AISI 316Ti Square Tubing, 316Ti Stainless Steel Seamless Tube, ASTM A249 TP 316Ti Welded Tubing, 316Ti Stainless Steel Pipe supplier, ASTM A269 TP 316Ti SS Seamless Pipe

Table Of Content

What is Stainless Steel 316Ti Pipe?
Different Forms of 316Ti Stainless Steel Tubes
Stainless Steel 316Ti Pipe Material Specifications
Mechanical Strength of Stainless Steel 316Ti Pipes
Equivalent Grades of SS 316Ti Pipes
Chemical Properties of Stainless Steel 316Ti Pipes
Stainless Steel 316Ti Pipe Size Chart in MM
Physical Characteristics of Stainless Steel 316Ti Pipes
Working Pressure of TP316Ti Stainless Steel Pipes
SS 316Ti Seamless Tube (ASTM A269) Weight Chart

What is Stainless Steel 316Ti Pipe?

Stainless Steel 316Ti Pipe is a Titanium-stabilized version of 316 stainless steel, an austenitic chromium-nickel alloy with added molybdenum for enhanced corrosion resistance. While grade 316 is already known for its superior resistance to general corrosion, pitting, and crevice corrosion compared to 304 stainless steel, the Titanium addition in 316Ti offers improved stability at high temperatures.

Titanium prevents the formation of chromium carbide precipitates (sensitization) at elevated temperatures between 425°C and 815°C, which typically lead to intergranular corrosion. By forming Titanium carbides instead, 316Ti stainless steel pipes maintain their corrosion resistance even after prolonged exposure to high heat. This makes them suitable for applications involving elevated temperatures, continuous heat cycles, and aggressive environments.

316Ti stainless steel pipes are available in seamless, welded, ERW, and EFW forms, manufactured under specifications like ASTM A312 and ASME SA312. They undergo stringent mechanical tests including tensile, yield, flattening, hydrostatic, and non-destructive testing to ensure durability and reliability in critical applications.

Key Features and Characteristics:

Titanium stabilized – prevents sensitization and intergranular corrosion.
Superior corrosion resistance – performs well in severe environments, including marine and chemical industries.
Enhanced high-temperature strength – maintains mechanical properties under continuous heat exposure.
Good weldability – weld annealing required only in high-stress applications.
Improved resistance to acids and chlorides – thanks to added molybdenum.

Different Forms of 316Ti Stainless Steel Tubes

SS 316Ti Pipe in India, ASTM A312 TP316Ti Pipes, 316Ti Stainless Steel ERW Pipe, SS 316Ti Industrial Pipe, 316Ti Stainless Steel Pipe, 316Ti Stainless Steel Tubing, ASME SA 312 Grade 316Ti ERW Pipe, AISI 316Ti Polished Pipe, Stainless Steel 316Ti Seamless Pipe

Stainless Steel 316Ti Pipe Material Specifications

International Specification	ASTM A312/ ASME SA 312 TP 316ti
Seamless Pipes Size	OD: 4 to 219mm Wall Thickness: 0.5 to 20mm
Welded Pipe Size	Outer Diameter: 5.0 – 1219.2 mm
EFW Pipe Size	Outer Diameter: 5.0 – 1219.2 mm
Wall Thickness	Schedule 5, Schedule 40, Schedule10, Schedule 80, Schedule 160, Schedule 80S, Schedule XXS, Schedule XS
techniques	EFW/ Seamless / ERW / Welded / LSAW/ Fabricated / Seam-Welded / CDW/ Redrawn
Form	Round, Square, Rectangular
Length	Double Random & Required Length End, Single Random, Plain End, Treaded, Beveled End
Condition	Hot Finished, Annealed and Pickled, Bright Annealed, Polished, Cold Drawn

Mechanical Strength of Stainless Steel 316Ti Pipes

Temper	Annealed
Tensile Rm	75	ksi (min)
Tensile Rm	515	MPa (min)
R.p. 0.2% Yield	30	ksi (min)
R.p. 0.2% Yield	205	MPa (min)
Elongation (2” or 4D gl)	35	% (min)

Equivalent Grades of SS 316Ti Pipes

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316Ti	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2

Chemical Properties of Stainless Steel 316Ti Pipes

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 316Ti	0.08 max	2.0 max	0.75 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	10.00 – 14.00	68.395 min

Stainless Steel 316Ti Pipe Size Chart in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

Physical Characteristics of Stainless Steel 316Ti Pipes

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
Grade	Density (kg/m3)	Elastic Modulus (GPa)	0-1000C	0-3150C	0-5380C	at 1000C	at 5000C	Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
316TI	8000	193	15.9	16.2	17.0	14.2	18.7	500	740

Working Pressure of TP316Ti Stainless Steel Pipes

Pressure Rating (psig)
Pipe Size (inches)	Pipe Schedule	Temperature (oF)
Pipe Size (inches)	Pipe Schedule	100	200	300	400	500	600	650	700	750
1″	40	3168	2629	2362	2171	2019	1924	1867	1824	1810
	80	4213	3634	3265	3002	2791	2659	2580	2528	2501
	160	6140	5296	4759	4375	4068	3876	3761	3684	3646
1 1/2″	40	2257	1947	1750	1608	1496	1425	1383	1354	1340
	80	3182	2744	2466	2267	2108	2009	1949	1909	1889
	160	4619	3984	3580	3291	3060	2916	2829	2772	2743
2″	40	1902	1640	1474	1355	1260	1201	1165	1141	1129
	80	2747	2369	2129	1957	1820	1734	1682	1648	1631
	160	4499	3880	3486	3205	2980	2840	2755	2699	2671
3″	40	1806	1558	1400	1287	1196	1140	1106	1084	1072
	80	2553	2202	1979	1819	1691	1612	1564	1532	1516
	160	3840	3312	2976	2736	2544	2424	2352	2316	2280
4″	40	1531	1321	1187	1091	1014	967	938	919	909
	80	2213	1909	1715	1577	1466	1397	1355	1328	1314
	160	3601	3106	2791	2566	2386	2273	2206	2161	2138
5″	40	1342	1158	1040	956	889	847	822	805	797
	80	1981	1709	1535	1411	1312	1250	1213	1189	1176
	160	3414	2945	2646	2433	2262	2155	2091	2049	2027
6″	40	1219	1052	945	869	808	770	747	732	724
	80	1913	1650	1483	1363	1267	1208	1172	1148	1136
	160	3289	2836	2549	2343	2179	2076	2014	1973	1953
8″	40	1073	926	832	765	711	678	657	644	637
	80	1692	1459	1311	1205	1121	1068	1036	1015	1005
	160	3175	2738	2460	2262	2103	2004	1944	1905	1885
10″	40	974	840	755	694	645	615	596	584	578
	80	1609	1388	1247	1147	1066	1016	986	966	956
	160	3147	2714	2439	2242	2085	1986	1927	1880	1868

SS 316Ti Seamless Tube (ASTM A269) Weight Chart

316Ti Seamless Tubes NPS	Outside Diameter		316Ti Seamless Tubes Wall Thickness			Weight	Weight
316Ti Seamless Tubes NPS	in	mm	in	mm	Sched	kg/Mtr	Lb/ft
1/2″	0.840	21	0.109	2.769	40 STD	1.268	0.851
			0.147	3.734	80 STD	1.621	1.088
3/4″	1.050	27	0.113	2.870	40 STD	1.684	1.131
			0.154	3.912	80 STD	2.195	1.474
1″	1.315	33	0.133	3.378	40 STD	2.501	1.679
			0.179	4.547	80 STD	3.325	2.172
1 1/4″	1.660	42	0.140	3.556	40 STD	3.385	2.273
			0.191	4.851	80 STD	4.464	2.997
1 1/2″	1.900	48	0.145	3.683	40 STD	4.048	2.718
			0.200	5.080	80 STD	5.409	3.361
2″	2.375	60	0.154	3.912	40 STD	5.441	3.653
			0.218	5.537	80 STD	7.480	5.022
2 1/2″	2.875	73	0.203	5.516	40 STD	8.629	5.793
			0.276	7.010	80 STD	11.411	7.661
3″	3.500	89	0.216	5.486	40 STD	11.284	7.576
			0.300	7.620	80 STD	15.272	10.253
4″	4.500	114	0.237	6.020		16.073	10.790
			0.337	8.560		22.318	14.983
6″	6.625	168	0.188	4.775		19.252	12.924
			0.203	5.516		20.739	13.923
			0.219	5.563		22.318	14.983
			0.250	6.350		25.354	17.021
			0.280	7.112	40 STD	58.263	18.974
			0.312	7.925		31.334	21.036
			0.375	9.525		37.285	25.031
			0.432	10.973	80 XHY	42.561	28.573
			0.500	12.700		48.719	32.708
8″	8.625	219	0.188	4.775		25.233	16.940
			0.203	5.156		27.198	18.259
			0.219	5.563		29.286	19.661
			0.250	6.350	20	33.308	22.361
			0.277	7.036	30	36.786	24.696
			0.322	8.179	40	42.352	28.554
			0.375	9.525		49.216	33.041
			0.406	10.312	60	53.085	35.638
			0.500	12.700	80 XHY	64.627	43.388
10″	10.750	273	0.188	4.775		31.588	21.207
			0.219	5.563		36.689	24.631
			0.250	6.350	20	41.759	28.035
			0.307	7.798	30	51.002	34.240
			0.344	8.738		56.946	38.231
			0.365	9.271	40 STD	63.301	40.483
			0.438	11.125		71.852	48.238
			0.500	12.700	60 XHY	81.530	54.735
			0.594	15.088	80	95.969	64.429
12″	12.750	324	0.188	4.775		37.570	25.222
			0.219	5.563		43.657	29.309
			0.250	6.350		49.713	33.375
			0.281	7.137		55.739	37.420
			0.312	7.925		61.735	41.445
			0.375	9.525		73.824	49.562
			0.406	10.312		79.727	53.525
			0.500	12.700		97.438	65.415
			0.562	14.275		108.966	73.154
14″	14.000	356	0.188	4.775		41.308	27.732
			0.219	5.563		48.012	32.233
			0.250	6.350	20	54.685	36.713
			0.281	7.137		61.327	41.172
			0.312	7.925		67.939	45.611
			0.375	9.525	STD	81.281	54.568
			0.438	11.125	40	94.498	63.441
			0.500	12.700	XHY	107.381	72.090
			0.625	15.875		132.983	89.278
16”	16.000	406	0.188	4.775		47.290	21.748
			0.219	5.563		54.980	36.910
			0.250	6.350	10	62.639	42.053
			0.281	7.137		70.268	47.174
			0.312	7.925	20	77.866	52.275
			0.344	8.738		85.677	57.519
			0.375	9.525	30 STD	93.213	62.578
			0.438	11.125		108.433	72.797
			0.500	12.700	40 XHY	123.289	82.770
18″	18.000	457	0.219	5.563		61.948	41.588
			0.250	6.350		70.593	47.393
			0.281	7.137		79.208	53.176
			0.312	7.925	20	87.792	58.939
			0.375	9.525	STD	105.144	70.588
			0.438	11.125	30	122.369	82.152
			0.500	12.700	XHY	139.198	93.450
			0.562	14.275	40	155.904	104.666
			0.625	15.875		172.754	115.978
20″	20.000	508	0.250	6.350		78.547	52.733
			0.282	7.163		88.458	59.386
			0.312	7.925		97.719	65.604
			0.375	9.525	20 STD	117.075	78.598
			0.438	11.125		136.305	91.508
			0.500	12.700	30 XHY	155.106	104.130
			0.594	15.088	40	183.378	123.110
			0.625	15.875		192.640	129.328
			0.688	17.475		211.368	141.901
24″	24.000	610	0.250	6.350		94.456	63.413
			0.281	7.137		106.029	71.183
			0.312	7.925		117.573	18.932
			0.375	9.525	20 STD	140.938	64.618
			0.438	11.125		164.176	110.219
			0.500	12.700	XHY	186.923	125.490
			0.625	15.875		232.410	156.028
			0.688	17.475	40	255.148	171.293
			0.750	19.050		277.401	186.233
30″	30.000	762	0.250	6.350		118.318	79.433
			0.281	7.137		132.851	89.189
			0.312	7.925	10	147.353	98.925
			0.375	9.525	STD	176.731	118.648
			0.438	11.125		205.983	138.286
			0.500	12.700	20 XHY	234.647	157.530
			0.625	15.875	30	292.066	196.078
			0.688	17.475		320.817	215.380
			0.750	19.050		348.988	234.293
36″	36.000	914	0.250	6.350		142.180	95.453
			0.281	7.137		159.672	107.196
			0.312	7.925	10	177.133	118.918
			0.375	9.525	STD	215.525	142.678
			0.438	11.125		247.790	166.353
			0.500	12.700	20 XHY	282.372	198.570
			0.625	15.875		351.723	236.128
			0.688	17.475		386.487	259.467
			0.750	19.050		420.576	282.353
42″	42.000	1067	0.312	7.925		206.914	138.911
			0.375	9.525	STD	248.319	166.708
			0.500	12.700	XHY	33.097	221.610
			0.750	19.050		492.163	330.413
48″	48.000	1219	0.375	9.525	STD	284.112	190.738
			0.438	11.125		331.404	222.487
			0.500	12.700	XHY	377.822	253.650
			0.750	19.050		563.750	378.473
			0.875	22.225		655.969	440.383

Application of Stainless Steel 316Ti Pipes/Tubes

- Petrochemical Industry
- Chemical Industry
- Oil and Gas Industry
- Pulp & Paper Indusry
- Power Plant Industry
- Food Processing Industry
- Pharmaceuticals Industry
- Energy Industry
- Aerospace Industry

Frequently Asked Questions About SS 316Ti Pipes/Tubes

What makes Stainless Steel 316Ti Pipes different from standard 316 pipes?

316Ti pipes are Titanium-stabilized, which prevents carbide precipitation during high-temperature exposure. This makes them more reliable for long-term use in elevated temperatures compared to standard 316 pipes.

What are the advantages of using SS 316Ti Tubes in high-temperature applications?

SS 316Ti tubes offer enhanced resistance to intergranular corrosion, better creep strength, and improved mechanical properties when exposed to heat, making them suitable for boilers, furnaces, and heat exchangers.

Are Stainless Steel 316Ti Pipes resistant to corrosion?

Yes. Like 316L, 316Ti pipes provide excellent resistance to general corrosion, pitting, and crevice corrosion, especially in chloride-rich and acidic environments.

Can 316Ti Tubes be welded easily?

Yes. 316Ti tubes are weldable, but post-weld annealing may not always be necessary due to Titanium stabilization, which prevents sensitization and maintains corrosion resistance.

Where are 316Ti Pipes and Tubes commonly used?

They are widely used in chemical processing plants, oil & gas industries, marine equipment, heat exchangers, and high-temperature industrial systems.

Stainless Steel Pipes & Tubes

Materials

Our Products

Enquire Now

Fill out the form below, and our team will get in touch with you within 24 hours.
